25
5.7.4 Color Display (Command Index 11)
Description: CLR.76543210 means 8 bit positions of the Command Data.
BIT NUMBER FUNCTION
76543210
0 0 Alarm 2 Color AMBER
0 1 Alarm 2 Color GREEN
1 0 Alarm 2 Color RED
0 0 Alarm 1 Color AMBER
0 1 Alarm 1 Color GREEN
1 0 Alarm 1 Color RED
0 0 Normal Color AMBER
0 1 Normal Color GREEN
1 0 Normal Color RED
Example: Set Normal color green, Alarm 1 color red, Alarm 2 color amber
The command data is 00001001Bin = 09Hex. Send *W1109
5.7.5 Alarm 1 Configuration (Command Index 09)
Description: ALR1CNG.76543210 means 8 bit positions of the Command Data.
BIT NUMBER FUNCTION
76543210
0 Alarm 1 at Power On Disable
1 Alarm 1 at Power On Enable
0 Loop Break Time Disable
1 Loop Break Time Enable
0 0 Active Above
0 1 Active Below
1 0 Active Hi/Lo
1 1 Active Band (Deviation only)
0 Normally Open
1 Normally Closed
0 Unlatch
1 Latch
0 Absolute
1 Deviation
0 Disable Alarm 1 /
Retransmission
1 Enable Alarm 1 /
Retransmission
Example:Set Alarm 1 Enable, Deviation, Unlatch, N.C., Band, Loop Disable, Alarm at
Power On Enable. The command data is 10111011Bin = BBHex.
Send: *W09BB
