Omega i-SERIES User Manual

Table 5.4 Command Letters and Suffix for Process/Strain Gauge Instrument with
10 Linearization Points
Command Command Function Command # Of Default
Index Bytes Characters Value
RW 01 SP1 3 6 200000
RW 02 SP2 3 6 200000
GPRW 03 RDGOFF 3 6 200000
RW 04 ANLOFF 3 6 400000
RW 05 ID 2 4 0000
-06 N/A - --
RW 07 INPUT 1 2 04
GPRW 08 RDGCNF 1 2 4A
RW 09 AL1CNFG 1 2 00
RW 0A AL2CNFG 1 2 00
RW 0B LOOP BREAK TIME 2 4 003B
RW 0C OUT1CNF 1 2 00
RW 0D OUT2CNF 1 2 60
RW 0E RAMPTIME 2 4 0000
RW 0F ANLSCL 3 6 9186A0
RW 10 COMM.PARAMETERS 1 2 0D
RW 11 COLOR 1 2 09
RW 12 AL1LO 3 6 A003E8
RW 13 AL1HI 3 6 200FA0
GPRW 14 RDGSCL 3 6 100001
RW 15 AL2LO 3 6 A003E8
RW 16 AL2HI 3 6 200FA0
GPRW 17 PB1/DEAD BAND 2 4 00C8
GPRW 18 RESET 1 2 4 00B4
GPRW 19 RATE 1 2 4 0000
GPRW 1A CYCLE 1 1 2 07
-1B N/A - - -
GPRW 1C PB2/DEAD BAND 2 4 00C8
GPRW 1D CYCLE 2 1 2 07
RW 1E SOAK TIME 2 4 0000
RW 1F BUS FORMAT 1 2 14
GPRW 20 DATA FORMAT 1 2 02
RW 21 ADDRESS 1 2 01
RW 22 Transit Time Interval 2 4 0010
-23 N/A - --
RW 24 Miscellaneous 1 2 00
RW 25 C.J. OFFSET ADJ. 3 6 200000
RW 26 Recognition Character 1 2 2A
RW 27 %LOW 1 2 00
RW 28 %HI 1 2 63
