Omega i-SERIES User Manual

Command Letters and Suffixes Continued
Command Command Function Command # Of Default
Index Bytes Characters Value
RW 0F ANLSCL 3 6 9186A0
RW 10 COMM.PARAMETERS 1 2 0D
RW 11 COLOR 1 2 09
RW 12 AL1LO 3 6 A003E8
RW 13 AL1HI 3 6 200FA0
GPRW 14 RDGSCL 3 6 100001
RW 15 AL2LO 3 6 A003E8
RW 16 AL2HI 3 6 200FA0
GPRW 17 PB1/DEAD BAND 2 4 00C8
GPRW 18 RESET 1 2 4 00B4
GPRW 19 RATE 1 2 4 0000
GPRW 1A CYCLE 1 1 2 07
-1B N/A - - -
GPRW 1C PB2/DEAD BAND 2 4 00C8
GPRW 1D CYCLE 2 1 2 07
RW 1E SOAK TIME 2 4 0000
RW 1F BUS FORMAT 1 2 14
GPRW 20 DATA FORMAT 1 2 02
RW 21 ADDRESS 1 2 01
RW 22 Transit Time Interval 2 4 0010
-23 N/A - --
RW 24 Miscellaneous 1 2 00
RW 25 C.J. OFFSET ADJ. 3 6 200000
RW 26 Recognition Character 1 2 2A
RW 27 %LOW 1 2 00
RW 28 %HI 1 2 63
D 01 DISABLE ALARM 1 0 0 -
D 02 DISABLE ALARM 2 0 0 -
D 03 STANDBY 0 0 -
D 04 DISABLE SELF 0 0 -
E 01 ENABLE ALARM 1 0 0 -
E 02 ENABLE ALARM 2 0 0 -
E 03 DISABLE STANDBY 0 0 -
E 04 ENABLE SELF 0 0 -
X 01 SEND READING 0 0 -
X 02 SEND PEAK READING 0 0 -
X 03 SEND VALLEY READING 0 0 -
U 01 SEND ALARM STATUS 0 0 -
U 03 SEND SW VERSION 0 0 -
V 01 SEND DATA STRING 0 0 -
Z 02 HARD RESET 0 0 -
15
