5.7.8 Output 1 Configuration (Command Index 0C)
Description: OUT1CNG.76543210 means 8 bit positions of the Command Data.
BIT NUMBER FUNCTION
76543210
0 Auto Tune PID Stop
1 Auto Tune PID Start
0 Anti Wind Up Disable
1 Anti Wind Up Enable
0 Auto PID Disable
1 Auto PID Enable
0 Reverse
1 Direct
0 Analog Proportional 0 – 20 mA
1 Analog proportional 4 – 20 mA
0 Time Proportional On/Off
1 Time Proportional PID
Example: Set PID, Direct, Auto PID Enable, Anti Integral Enable, Auto PID Stop.
The command data is 00010111Bin = 2Fhex. Send: *W0C17
5.7.9 Output 2 Configuration (Command Index 0D)
Description: OUT2CNG.76543210 means 8 bit positions of the Command Data.
BIT NUMBER FUNCTION
765 43210
0 0 0 Damping 0
0 0 1 Damping 1
0 1 0 Damping 2
0 1 1 Damping 3
1 0 0 Damping 4
1 0 1 Damping 5
1 1 0 Damping 6
1 1 1 Damping 7
0 Soak Disable
1 Soak Enable
0 Ramp Disable
1 Ramp Enable
0 Auto PID Disable
1 Auto PID Enable
0 Reverse
1 Direct
0 Time Proportional On/Off
1 Time Proportional PID
Example: Set On/Off, Reverse, Auto PID Disable, Ramp Disable, Soak Disable,
Damping 4. The command data is 10000101Bin = 80Hex. Send: *W0D85
