Omega i-SERIES User Manual

4242
Example:
SEND TO DEVICE: Address 05, read (03) register 04 - inactive (see Table 6.2)
DEVICE FUNCTION STARTING NUMBER OF CRC
ADDRESS CODE REGISTER REGISTERS
05 03 00 04 00 01 C4 4F
RETURNED FROM DEVICE:
DEVICE FUNCTION ERROR CRC
ADDRESS CODE RESPONSE
05 83 02 81 30
Example:
SEND TO DEVICE: Address 120 (Hex 78), write (06) to register 35 (Hex 23) - inactive
(see Table 6.2)
DEVICE FUNCTION REGISTER DATA/ CRC
ADDRESS CODE VALUE
78 06 00 23 00 00 73 A9
RETURNED FROM DEVICE:
DEVICE FUNCTION ERROR CRC
ADDRESS CODE RESPONSE
78 86 02 12 78
Example:
SEND TO DEVICE: Address 01, write (06) to register 12 (Hex C) value 300 (Hex 12C)
–out of range (see Table 6.2)
DEVICE FUNCTION REGISTER DATA/ CRC
ADDRESS CODE VALUE
01 06 00 0C 01 2C 49 84
RETURNED FROM DEVICE:
DEVICE FUNCTION ERROR CRC
ADDRESS CODE RESPONSE
01 86 03 02 61
When device returns an error massage, it add 80 Hex to the Function Code
(03 + 80 = 83 or 06 + 80 = 86)
