Omega i-SERIES User Manual

51
CRC Calculation Continued
Function code Two byte (16 bit) Register Overflow
HB LB Bit
A001 1010 0000 0000 0001
Exclusive OR 1101 1001 0001 0101
5th shift 0110 1100 1000 1010 1
A001 1010 0000 0000 0001
Exclusive OR 1100 1100 1000 1011
6th shift 0110 0110 0100 0101 1
A001 1010 0000 0000 0001
Exclusive OR 1100 0110 0100 0100
7th shift 0110 0011 0010 0010 0
8th shift 0011 0001 1001 0001 0
Fourth Byte 08 0000 1000
Exclusive OR 0011 0001 1001 1001
1st shift 0001 1000 1100 1100 1
A001 1010 0000 0000 0001
Exclusive OR 1011 1000 1100 1101
2nd shift 0101 1100 0110 0110 1
A001 1010 0000 0000 0001
Exclusive OR 1111 1100 0110 0111
3rd shift 0111 1110 0011 0011 1
A001 1010 0000 0000 0001
Exclusive OR 1101 1110 0011 0010
4th shift 0110 1111 0001 1001 0
5th shift 0011 0111 1000 1100 1
A001 1010 0000 0000 0001
Exclusive OR 1001 0111 1000 1101
6th shift 0100 1011 1100 0110 1
A001 1010 0000 0000 0001
Exclusive OR 1110 1011 1100 0111
7th shift 0111 0101 1110 0011 1
A001 1010 0000 0000 0001
Exclusive OR 1101 0101 1110 0010
8th shift 0110 1010 1111 0001 0
Fifth Byte 00 0000 0000
Exclusive OR 0110 1010 1111 0001
1st shift 0011 0101 0111 1000 1
A001 1010 0000 0000 0001
Exclusive OR 1001 0101 0111 1001
2nd shift 0100 1010 1011 1100 1
A001 1010 0000 0000 0001
Exclusive OR 1110 1010 1011 1101
3rd shift 0111 0101 0101 1110 1
A001 1010 0000 0000 0001
Exclusive OR 1101 0101 0101 1111
4th shift 0110 1010 1010 1111 1
A001 1010 0000 0000 0001
Exclusive OR 1100 1010 1010 1110
5th shift 0110 0101 0101 0111 0
6th shift 0011 0010 1010 1011 1
