Safety Accessories Supplementary Sheet
30 OMICRON
5.5 Disconnection
To disconnect the SAA2 from the main device:
1. Make sure that the main device to which the SAA2 is connected to is switched off.
Death or severe injury caused by high voltage or current possible.
Observe the five safety rules (see 1.2.2 Five safety rules).
2. Press the Emergency Stop button on the main device or test system (in case of VOTANO 100 the
Emergency button on SAB1 safety box) and lock the main device with a physical key (CPC 80 and
CPC 100) or by pressing the software lock button (TESTRANO 600 and VOTANO 100).
NOTE! CIBANO 500 and COMPANO 100 do not have a separate physical key nor a software lock
function.
3. Disconnect the test system from the asset under test as described in the User Manual of the main
device.
4. Disconnect the connection cables between the SAA2 control unit and signal lamps and remove the
signal lamps.
5. Disconnect the safety interface cable between the SAA2 control unit and the main device.
6. Loosen the locking screws on the Safety Connector Dongle and remove the Safety Connector
Dongle from the SAFETY output of the SAA2 control unit and plug it in the SAFETY output
connector on the main device and tighten the locking screws. For VOTANO 100 remove the SAB1
cable from the last daisy chained SAA2 control unit SAFETY output connector and after removing all
safety accessories insert and attach into the SAFETY output connector on VOB2.
7. The SAA2 has now been removed and the main device has the required Safety Accessory Dongle
installed on the SAFETY output connector.
5.6 Cleaning
To clean the SAA2, use a cloth dampened with isopropanol alcohol.
Death or severe injury caused by high voltage or current possible.
Before cleaning the SAA2, always disconnect it from the main device.
