Omicron SAA1 - Signal Lamps

SAA2 Warning Lamp
33 OMICRON
5.7.2 Signal lamps
Table 16: SAA2 signal lamp specifications
Characteristic Rating
Operating voltage 24 V DC / 5 W
Diameter / Signal effect 38 mm / LED (red, green)
Protection rating IP52
Mounting
Magnet, ¼” tripod screw, mounting ring and four M4 × 6 mm nuts
for fixed mounting
Input/output connections 2
Connection cable
Length 8 m
Table 17: Climate
Characteristic Rating
Temperature Operating –10 ºC…+50 ºC / +22 ºF…+131 ºF
Storage –30 ºC…+70 ºC / –22 ºF…+158 ºF
Max. altitude Operating 2 000 m / 6 560 ft
Storage 12 000 m /40 000 ft
Table 18: Mechanical data
Characteristic Rating
Dimensions (w × h × d) 200 mm × 80 mm × 70 mm
7.9 inch × 3.1 inch × 2.8 inch
Weight 400 g / 0.9 lb (without cable)
