Omicron SAA1 User Manual

SAA2 Warning Lamp
31 OMICRON
5.7 Technical data
5.7.1 Control unit
Table 12: SAA2 control unit specifications
Characteristic Rating
Operating voltage 24 V DC / 40 W
Interface SAFETY IN 9-pin D-SUB-M connector with locking thumb screws
Interface SAFETY OUT 9-pin D-SUB-F connector with locking thumb screws
Safety interface cable
Length 1.5 m
Max. cascadability 2 times (only for CPC 80 / CPC 100)
Cascadability
Max. number of signal lamps per channel
6 per SAA2 control unit, all combinations on channel
possible, for example 4/2
Max. number of channels per control unit 2
Table 13: Climate
Characteristic Rating
Temperature Operating 0 ºC…+50 ºC / +32 ºF…+122 ºF
Storage –30 ºC…+70 ºC / –22 ºF…+158 ºF
Max. altitude Operating 2 000 m / 6 560 ft
Storage 12 000 m / 40 000 ft
Humidity < 95% relative humidity, non-condensing
Table 14: Mechanical data
Characteristic Rating
Dimensions (w × h × d) 180 mm × 111 mm × 44 mm
7.1 inch × 4.4 inch × 1.74 inch
Weight 620 g / 1.6 lb (without cable)

Omicron SAA1 Specifications

General

Brand	Omicron
Model	SAA1
Category	Safety Equipment
Language	English
