2-34 Installation Instructions
Installation on G3 Cabinets
External Return Bin Installation and Service Guide/67-2038 Rev D © 2011 Omnicell, Inc.
3. Tilt the worksurface up, pull it forward, then lift it up and away. Set it aside.
Figure 2-91. Tilting the worksurface
Figure 2-92. Pulling the worksurface forward
Figure 2-93. Lifting the worksurface
