2-44 Installation Instructions
Installation on G3 Cabinets with G4 Console Upgrade
External Return Bin Installation and Service Guide/67-2038 Rev D © 2011 Omnicell, Inc.
7. Put the plate back into the opening and screw it into place on the inside of the frame.
8. Pull excess ERB PowerCom cable inside the frame and bundle the cables with cable ties.
9. Attach the ERB PowerCom cable to the bracket on the inside of the chassis for strain relief.
Figure 2-113.
Plate in place
ERB PowerCom cable
