© 2011 Omnicell, Inc. External Return Bin Installation and Service Guide/67-2038 Rev D
Installation Instructions 2-73
Daisy Chains
Figure 2-178. Loosening the metal plate nuts
3. Maneuver the metal plate around the sheet metal tabs and nuts. Remove the lower rim first.
Figure 2-179. Removing the metal plate
Note: Do not completely remove the nuts, one full turn should be enough.
