A-39
Appendices
EtherCAT Communication Unit USER’S MANUAL (3G3AX-MX2-ECT)
A-5 Sysmac Error Status Codes
App
A-5-2 Error Descriptions
Event name Inverter Warning Event code 04BB0000 hex
Meaning An Inverter warning was detected.
Source EtherCAT Master Function Module Source details Slave Detection
timing
Continuously
Error attributes Level Minor fault Recovery Error reset (after
resetting slave
errors)
Log category System
Effects User program Continues. Operation Not affected.
Indicators EtherCAT NET RUN EtherCAT NET ERR EtherCAT LINK/ACT
--- --- ---
System-defined
variables
Variable Data type Name
None --- ---
Cause and
correction
Assumed cause Correction Prevention
An Inverter warning was detected. Read the value in slave object 3000
hex sub-index 4F hex and check the
warning details. Remove the cause of
the warning accordingly. Then exe-
cute an error reset with slave object
5000 hex or a fault reset with 6040
hex.
Depends on the nature of the error.
Attached
information
None
Precautions/
Remarks
None
Event name Inverter Trip Event code 04BC0000 hex
Meaning An Inverter trip was detected.
Source EtherCAT Master Function Module Source details Slave Detection
timing
Continuously
Error attributes Level Minor fault Recovery Error reset (after
resetting slave
errors)
Log category System
Effects User program Continues. Operation Motor stops.
Indicators EtherCAT NET RUN EtherCAT NET ERR EtherCAT LINK/ACT
--- --- ---
System-defined
variables
Variable Data type Name
None --- ---
Cause and
correction
Assumed cause Correction Prevention
An Inverter trip was detected. Read slave object 3000 hex sub-index
13 hex (cause) and 3000 hex sub-
index 14 hex (inverter status) values
and check the details. Remove the
cause of the trip accordingly. Then
execute an error reset with slave
object 5000 hex or a fault reset with
6040 hex.
Depends on the nature of the error.
Attached
information
None
Precautions/
Remarks
None
