When Normal Deceleration Stop Is Selected (Stop Selection
(3008Hex-0CHex) = “0”)
• Deceleration stop according to the selected deceleration hold time. For details, refer to 6-6-1 Accel-
eration/Deceleration T
ime Setting on page 6-33.
When Free Run Stop Is Selected (Stop Selection (3008Hex-0CHex)
= “1”)
• By the free run stop function, power to the motor is cut off to stop the motor.
• T
o use external braking, select free-run stop. Using external braking midway during a deceleration
stop may cause an overload or overcurrent.
• If operation is started again during free run operation, the inverter will restart according to Free Run
Stop Restart Operation Selection (3052Hex-2AHex).
6 Basic Settings
6-42
M1 Series EtherCAT Type User’s Manual (I670)
