7-8
Motor tuning
7-8-1
Motor Off-line Auto-tuning
To perform auto-tuning of the motor, perform the settings according to the control method in 7-1-3 Mo-
tor Parameter Settings on page 7-6, and then perform according to the following procedure.
Offline Auto-tuning of Induction Motor (IM Motor)
Offline auto-tuning consists of the following five steps:
• Presetting of parameters
• Selection of motor rotation during auto-tuning
• Execution of auto-tuning
• Processing after auto-tuning
• Corrective action in case of an error
1 Presetting of parameters
1) Set one of “0: IM V/f control,” “1: IM Dynamic torque vector control,” “3: IM V/f control with
speed sensor,” “4: IM Dynamic torque vector control with speed sensor
,” “5: IM Vector con-
trol without speed sensor” or “6: IM Vector control with speed sensor” to 1st Drive Control
Selection (3004Hex-2BHex)/2nd Drive Control Selection (3009Hex-0FHex).
2) Referring to 7-1-3 Motor Parameter Settings on page 7-6, set parameters matched to the
control method.
2 Tuning method
Check the machine status, and select either “2: Tune the motor parameters while rotating” or
“1: T
une the motor parameters while stopped” in 1st Auto Tuning Function Selection
(3007Hex-05Hex)/2nd Auto-tuning Selection Function Selection (3009Hex-13Hex). When the
wiring length has changed after rotation tuning is performed, tuning can be performed by “5:
Tune the motor %R1 and %X while stopped.”
3007Hex-05Hex/
3009Hex-13Hex data
Data to be tuned Tuning
Supplementary ex-
planation
1
Tune the motor pa-
rameters while stop-
ped
Primary resistance
%R1
(3007Hex-08Hex/
3009Hex-16Hex)
Leakage reactance
%X (3007Hex-09Hex/
3009Hex-17Hex)
Rated slip
(3007Hex-0DHex/
3009Hex-1BHex)
%X correction factor
(3007Hex-36Hex/
3009Hex-36Hex)
Tuning is performed in
a stop state.
When the motor can-
not be rotated.
7 Vector Control and Applied Functions
7-65
M1 Series EtherCAT Type User’s Manual (I670)
7-8 Motor tuning
7
7-8-1 Motor Off-line Auto-tuning
To Next Page
