Parameter No. Function name Data
Default da-
ta
Unit
3010Hex-29Hex Input Terminal Monitor
Bit15: -
Bit14: -
Bit13: -
Bit12: EN2
Bit11: EN1
Bit10: -
Bit9: -
Bit8: -
Bit7: -
Bit6: DI5
Bit5: DI4
Bit4: DI3
Bit3: DI2
Bit2: DI1
Bit1: DI7
Bit0: DI6
0 -
Universal DO
When “27: OPO (Option board output)” is allocated to the output terminal, output is performed from the
corresponding output terminal when data is written to the Communication Data Terminal [DO]
(3002Hex-08Hex) from communication regardless of inverter operation.
Parameter No. Function name Data
Default da-
ta
Unit
3002Hex-08Hex
Communication Data Terminal
[DO]
Bit8: RO
Bit0: DO1
0 -
8-9-27
Protection/Maintenance Mode Selection Function
Main circuit capacitor life judgment selection, main circuit capacitor life judgment, inrush current pre-
vention resistor overheat detection, and braking transistor broken detection operations can be select-
ed and set as combined operations.
Parameter No. Function name Data
Default
data
Unit
3008Hex-63He
x
Protection/Maintenance Function
Mode Selection
0 to 255 80 -
Set function settings as binary values to their respective bits, and set the resulting data as decimal
data to Protection/Maintenance Function Mode Selection (3008Hex-63Hex).
The following shows the settings of each bit and each function.
Bit Function Data = 0 Data = 1
Bit 0 to 2 Reserved - -
Bit 3
Main circuit capacitor life judgment stand-
ards selection
Default value User setting
Bit 4 Judge main circuit capacitor life Disable Enable
Bit 5
Detect inrush current prevention resistor
overheat
Enable Disable
8 Other Functions
8-141
M1 Series EtherCAT Type User’s Manual (I670)
8-9 Other Operation Functions
8
8-9-27 Protection/Maintenance Mode Selection Function
