Parameter No. Data Description Reference item Page
3005Hex-15Hex,
3005Hex-1CHex
0 RUN: Run Signal Run Signal page 6-61
1 FAR1:
Frequency arrival signal 1
(constant speed)
Constant speed arrival
signal
page 6-62
2 FAR2:
Over set frequency arrival
signal 1
Frequency arrival signal
page
8-78
3 UV: Signal during undervoltage
Restart after Momentary
Power Failure
page
8-45
4 B/D: Detected torque polarity Torque control page 7-31
5 IOL: Inverter output limiting Inverter output limiting
page
8-93
6 IPF:
Auto-restarting after mo-
mentary power failure
Restart after Momentary
Power Failure
page
8-45
7 THM: Thermal warning
Electronic Thermal Warn-
ing
page 6-21
8 Do not set. - -
10 IRDY: Operation ready signal
Operation ready comple-
tion signal
page 6-61
15 AX:
Switch MC on the input
power lines (for inverter in-
put-side electromagnetic
contactor)
Switch MC on the input
power lines
page
8-94
16 TU:
Pattern operation stage
transition
Pattern Operation Func-
tion Selection
page 6-28
17 TO:
Pattern operation cycle
completed
Pattern Operation Func-
tion Selection
18 Do not set.
Pattern Operation Func-
tion Selection
19 Do not set.
Pattern Operation Func-
tion Selection
20 Do not set.
Pattern Operation Func-
tion Selection
21 FAR2: Frequency arrival signal 2 Frequency arrival signal
page
8-78
22 IOL2:
Inverter output limiting with
delay
Inverter output limiting
page
8-93
25 FAN: Cooling fan in operation
Cooling FAN Control
Method Selection
page
8-88
26 TRY: Auto-resetting Trip Retry Operation
page
8-50
27 Reserved
page
8-140
28 OHF: Fin overheat warning
Cooling fin overheat
warning
page
8-90
29 SY: Synchronization completed
Simultaneous Start
Synchronized Run Oper-
ation
-
30 LIFE: Lifetime alarm Lifetime alarm (LIFE)
page
8-88
31 FDT2:
Over set frequency arrival
signal 2
Frequency arrival signal
page
8-78
33 REFOFF: Reference loss detected Frequency Reference page 6-24
8 Other Functions
8-29
M1 Series EtherCAT Type User’s Manual (I670)
8-2 Multifunction Input/Output Functions List
8
8-2-2 Multifunction Output Selection
