Parameter No. Function name Data
Default da-
ta
Unit
3008Hex-46Hex
Anti-regenerative Control Func-
tion Selection
0: Disable
2: Torque limit control with
forced stop after three
times deceleration time has
passed
3: Main Circuit DC V
oltage
control with forced stop af-
ter three times deceleration
time has passed
4: Torque limit control with-
out forced stop
5: Main Circuit DC Voltage
control without force-to-
stop
0 -
3020Hex-0FHex Anti-regenerative Control Level
0.0 to 50.0
999: Auto
999 %
3008Hex-4DHex
Frequency Rising Limit for Tor-
que Limit
0.0 to 590.0 5.0 Hz
Related function
Input Terminal [DI1] to [DI7] Function Selection
(3005Hex-02Hex to 3005-06Hex, 3005Hex-63Hex,
3005Hex-64Hex) = "82 (AR-CCL: Cancel anti-re-
generative control)"
• Anti-regenerative control sometimes increases the deceleration time.
• When the braking unit is connected, do not use anti-regenerative control. Anti-regenerative control
sometimes acts simultaneously with operation of the braking unit and the deceleration time is not as
set.
•
When the deceleration time is too short, the Main Circuit DC Voltage of the inverter sometimes rises
quickly and anti-regenerative control cannot keep up. In instances like this, set a longer deceleration
time.
Torque Limit (3008Hex-46Hex = 2, 4)
• A feature is that response is high and an overvoltage trip is less likely to occur even by an impact
load. The frequency control value can be adjusted by Anti-regenerative Control Level
(3020Hex-0FHex), and, when the Anti-regenerative Control Level (3020Hex-0FHex) is increased,
frequency control increases.
• This is enabled during acceleration, constant speed and deceleration.
•
The output frequency is controlled until braking torque reaches almost 0 (zero).
• Although Anti-regenerative Control Level (3020Hex-0FHex) can be adjusted, normally adjustment is
not required.
• When the output frequency is limited, an overvoltage trip sometimes is generated as anti-regenera-
tive control is limited. Anti-regenerative capability can be improved by setting a larger Frequency
Rising Limit for Torque Limit (3008Hex-4DHex).
Main Circuit DC Voltage Control (3008Hex-46Hex = 3, 5)
• This is enabled only at deceleration.
8 Other Functions
8-75
M1 Series EtherCAT Type User’s Manual (I670)
8-8 Functions Related to Protection, Warning and Various Output Signals
8
8-8-2 Anti-regenerative Control Function
To Next Page
