Sysmac common
code (hex)
Alarm code
(hex)
Contents
08870000 0018 2nd Motor Overload Protection
08880000 0014 Thermistor Error
08890000 0036 Hardware Error
088A0000 0039 Enable Circuit Failure
088B0000 0010 Inrush Current Prevention Circuit Error
183D0000 001F EEPROM Error
183E0000 0021 CPU Error
183F0000 0033 Data Save Error during Undervoltage
280F0000 000B Input Phase Loss Error
28100000 002E Output Phase Loss Error
28110000 0020 Operator Communications Error
28130000 0022 EtherCAT Communications Error
28140000 0068 Analog Input Reference Command Loss Detected
389C0000 001B Overspeed
389D0000 0024 Operation Error
389E0000 0025 Tuning Error
38A00000 002A Step-out Detection/Magnetic Pole Position Detection Error during
Startup
38A10000 002F Speed Mismatch or Excessive Speed Deviation
38A20000 0038 Positioning Control Error
38A30000 001C Abnormal Setting Related to the PG Option Card
38A50000 00FD Locked by Password
38A60000 0032 Magnetic Pole Position Detection Error
38A70000 0034 Excessive Position Deviation Error
68430000 0012 External Trip
68440000 00FE Mock Alarm
68460000 0065 Motor Overload Warning
68470000 0066 Cooling Fin Overheat Warning
68480000 0067 Life Warning
68490000 0069 PID Warning Output
684A0000 006A Low Torque Detected
684B0000 006C Motor Run Time Over
684C0000 006D Number of Startups Over
96530000 0044 Communication Timeout with Sysmac Studio
Appendices
A-26
M1 Series EtherCAT Type User’s Manual (I670)
