When subindex 01 hex is not set, or when the power supply is cycled with Save not executed by
object 1010 hex, the value calculated based on 1st Maximum Output Frequency (F03) (3004-04
hex) and 1st Motor Pole Number (P01) (3007-02 hex) will be read.
When the power supply is cycled, the inverter reads the value saved by object 1010 hex.
However
, if 1st Maximum Output Frequency (F03) (3004-04 hex), 1st Motor Pole Number (P01)
(3007-02 hex), or Deceleration Time for Forced Stop (H56) (3008-39 hex) is changed with Save
executed by object 1010 hex, the value will be recalculated based on 1st Maximum Output
Frequency (F03) (3004-04 hex) and 1st Motor Pole Number (P01) (3007-02 hex).
• Read Value of Subindex 02 hex
When subindex 02 hex is not set, or when the power supply is cycled with Save not executed by
object 1010 hex, Deceleration Time for Forced Stop (H56) (3008-39 hex) will be converted in in-
crements of 1 s.
When the power supply is cycled, the inverter reads the value saved by object 1010 hex.
However, if 1st Maximum Output Frequency (F03) (3004-04 hex), 1st Motor Pole Number (P01)
(3007-02 hex), or Deceleration Time for Forced Stop (H56) (3008-39 hex) is changed with Save
executed by object 1010 hex, Deceleration Time for Forced Stop (H56) (3008-39 hex) will be con-
verted in increments of 1 s.
Index
(hex)
Sub-
index
(hex)
Object name
Setting
range
Unit
Default set-
ting
Data
attrib-
ute
Size
Ac-
cess
PDO
map
Complete
access
Modes of
operation
604D --- vl vpole number 02 to 80
hex
--- 04 hex --- 1 byte
(U8)
W --- Possible vl
• This object sets and displays the pole number.
• It has the same value as
1st Motor Pole Number (P01) (3007-02 hex).
Index
(hex)
Sub-
index
(hex)
Object name
Setting
range
Unit
Default set-
ting
Data
attrib-
ute
Size
Ac-
cess
PDO
map
Complete
access
Modes of
operation
605B --- Shutdown op-
tion code
1 --- 1 E 2 bytes
(INT16)
W --- Not possi-
ble
---
• This object sets the operation of the inverter during Shutdown (transition from the Operation enabled
state to the Ready to switch on state).
Index
(hex)
Sub-
index
(hex)
Object name
Setting
range
Unit
Default set-
ting
Data
attrib-
ute
Size
Ac-
cess
PDO
map
Complete
access
Modes of
operation
605C --- Disable opera-
tion option code
1 --- 1 E 2 bytes
(INT16)
W --- Not possi-
ble
---
• This object sets the operation of the inverter during Disable operation (transition from the Operation
enabled state to the Switched on state). “During Disable operation” refers to the duration in which
the inverter decelerates and then stops after Servo OFF (Disable operation).
Appendices
A-33
M1 Series EtherCAT Type User’s Manual (I670)
A-2 CoE Objects
A
A-2-8 Inverter Profile Objects
