Index
(hex)
Sub-
index
(hex)
Pa-
rame-
ter No.
Function name Monitor or data range
Default
data
Set-
ting
dur-
ing
RUN
Unit
PDO
map
3C M59 Motor Electronic
Thermal Monitor
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0 to 100
0 --- % Possible
(TxPDO)
3E M61 Inverter Internal
Air Temperature
Monitor
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
-3,276.8 to 3,276.7
0 --- °C Possible
(TxPDO)
3F M62 Fin Temperature
Monitor
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
-3,276.8 to 3,276.7
0 --- °C Possible
(TxPDO)
40 M63 Load Factor
Monitor
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
-3276.8 to 3276.7
0 --- % Possible
(TxPDO)
41 M64 Motor Output
Monitor
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
-3276.8 to 3276.7
% of rated power
0 --- % Possible
(TxPDO)
42 M65 Motor Output
Monitor on Alarm
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
-32,768 to 32,767
0 --- --- Possible
(TxPDO)
43 M66 Speed Detection
Monitor
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
-32,768 to 32,767
0 --- --- Possible
(TxPDO)
44 M67 Transmission Er-
ror Transaction
Code for RS485
Port
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
1: Improper FC (Non-existent param-
eter block specified)
2: Improper address (Non-existent
parameter number specified)
3: Improper data (Range error)
7: NAK (Link priority, no right,
write disabled)
71: Checksum error, CRC error
72: Parity error
73: Framing error, overrun error, buf-
fer full
0 --- --- Possible
(TxPDO)
45 M68 Reserved Do not use. --- --- --- ---
46 M69 Inverter rated
current
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00 to 9,999
0 --- A Possible
(TxPDO)
Appendices
A-57
M1 Series EtherCAT Type User’s Manual (I670)
A-4 Lists of Manufacturer Specific Objects 2
(Inverter Parameters)
A
A-4-1 M Group Parameter List (Monitor 1)
