Index
(hex)
Sub-
index
(hex)
Pa-
rame-
ter No.
Function name Monitor or data range
Default
data
Set-
ting
dur-
ing
RUN
Unit
PDO
map
45 Z68 Third Last Alarm
Info. Running
Status 3
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0000 to FFFF hex
Bit 15: ---
Bit 14: OL (Overload warning)
Bit 13: LOC (Light load detection)
Bit 12: OL2 (Overload warning 2)
Bit 11: OLP (During active drive)
Bit 10: LIFE (Life warning)
Bit 9: OHF (Fin Overheat warning)
Bit 8: TRY (During retry)
Bit 7: FAN (Fan operation signal)
Bit 6: Reserved
Bit 5: THM (Thermal warning)
Bit 4: IPF (During restart after instan-
taneous power failure)
Bit 3: SETM (2nd motor selection)
Bit 2: IRDY (Operation ready)
Bit 1: FDT1 (Over set Frequency ar-
rival)
Bit 0: FAR1 (Constant speed arrival)
0 --- --- Possible
(TxPDO)
55 Z84 Output Current
Monitor
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0.00 to 655.35
0 --- A Possible
(TxPDO)
Appendices
A-84
M1 Series EtherCAT Type User’s Manual (I670)
