Omron 3G3M1-A4004-ECT User Manual

Index
(hex)
Sub-
index
(hex)
Pa-
rame-
ter No.
Function name Monitor or data range
Default
data
Set-
ting
dur-
ing
RUN
Unit
PDO
map
23 X34 Latest Alarm In-
fo. Output Termi-
nal via Communi-
cation
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0000 to FFFF hex
Bit 15: ---
Bit 14: ---
Bit 13: ---
Bit 12: ---
Bit 11: ---
Bit 10: ---
Bit 9: ---
Bit 8: RO
Bit 7: ---
Bit 6: ---
Bit 5: ---
Bit 4: ---
Bit 3: ---
Bit 2: ---
Bit 1: DO2
Bit 0: DO1
0 --- --- Possible
(TxPDO)
24 X35 Latest Alarm In-
fo. Input Power
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00 to 9,999
0 --- kW Possible
(TxPDO)
