Model
Maxi-
mum
appli-
cable
motor
ca-
paci-
ty
[kW]
Recommended wire
size [mm2]
Inverter ground (G)
HHD mode HND mode
Allowable tempera-
ture (Note 1)
60°C 75°C 90°C
3G3M1-AB037-ECT - 3.7 3.5 3.5 3.5
Three-phase 200-V class (Panel internal temperature 40°C or less)
Model
Maxi-
mum
appli-
cable
motor
ca-
paci-
ty
[kW]
Recommended wire size [mm2]
Main power supply input (L1/R, L2/S, L3/T)
When DC reactor (DCR) is
used
Without DC reactor
HHD mode HND mode
Allowable tempera-
ture (Note 1)
Cur-
rent
value
[A]
Allowable tempera-
ture (Note 1)
Cur-
rent
value
[A]
60°C 75°C 90°C 60°C 75°C 90°C
3G3M1-
A2001-ECT
- 0.1 2.0 2.0 2.0 0.6 2.0 2.0 2.0 1.1
3G3M1-
A2002-ECT
3G3M1-
A2001-ECT
0.2 2.0 2.0 2.0 0.9 2.0 2.0 2.0 1.8
- 3G3M1-
A2002-ECT
0.4 2.0 2.0 2.0 1.6 2.0 2.0 2.0 2.6
3G3M1-
A2004-ECT
- 2.0 2.0 2.0 1.6 2.0 2.0 2.0 3.1
- 3G3M1-
A2004-ECT
0.75 2.0 2.0 2.0 3.0 2.0 2.0 2.0 4.9
3G3M1-
A2007-ECT
- 2.0 2.0 2.0 3.0 2.0 2.0 2.0 5.3
- 3G3M1-
A2007-ECT
1.1 2.0 2.0 2.0 4.3 2.0 2.0 2.0 6.7
3G3M1-
A2015-ECT
- 1.5 2.0 2.0 2.0 5.7 2.0 2.0 2.0 9.5
- 3G3M1-
A2015-ECT
2.2 2.0 2.0 2.0 8.3 2.0 2.0 2.0 12.8
3G3M1-
A2022-ECT
- 2.0 2.0 2.0 8.3 2.0 2.0 2.0 13.2
- 3G3M1-
A2022-ECT
3 2.0 2.0 2.0 11.7 2.0 2.0 2.0 17.9
3G3M1-
A2037-ECT
- 3.7 2.0 2.0 2.0 14.0 3.5 2.0 2.0 22.2
- 3G3M1-
A2037-ECT
5.5 2.0 2.0 2.0 19.9 3.5 2.0 2.0 28.5
3G3M1-
A2055-ECT
- 2.0 2.0 2.0 21.1 5.5 3.5 2.0 31.5
3G3M1-
A2075-ECT
3G3M1-
A2055-ECT
7.5 3.5 2.0 2.0 28.8 8.0 5.5 3.5 42.7
