Model
Maxi-
mum
appli-
cable
motor
ca-
paci-
ty
[kW]
Recommended wire size [mm2]
Brake resistance connection (P(+), DB)
HHD mode HND mode
HHD mode HND mode
Allowable tempera-
ture (Note 1)
Cur-
rent
value
[A]
Allowable tempera-
ture (Note 1)
Cur-
rent
value
[A]
60°C 75°C 90°C 60°C 75°C 90°C
3G3M1-
A2150-ECT
3G3M1-
A2110-ECT
15
2.0 2.0 2.0 9.4 2.0 2.0 2.0 7.5
3G3M1-
A2185-ECT
3G3M1-
A2150-ECT
18.5 2.0 2.0 2.0 12.7 2.0 2.0 2.0 9.0
- 3G3M1-
A2185-ECT
22 2.0 2.0 2.0 13.8 2.0 2.0 2.0 12.0
Model
Maxi-
mum
appli-
cable
motor
ca-
paci-
ty
[kW]
Recommended wire
size [mm2]
Inverter ground (G)
HHD mode HND mode
Allowable tempera-
ture (Note 1)
60°C 75°C 90°C
3G3M1-A2001-ECT - 0.1 2.0 2.0 2.0
3G3M1-A2002-ECT 3G3M1-A2001-ECT 0.2 2.0 2.0 2.0
- 3G3M1-A2002-ECT 0.4 2.0 2.0 2.0
3G3M1-A2004-ECT - 2.0 2.0 2.0
- 3G3M1-A2004-ECT 0.75 2.0 2.0 2.0
3G3M1-A2007-ECT - 2.0 2.0 2.0
- 3G3M1-A2007-ECT 1.1 2.0 2.0 2.0
3G3M1-A2015-ECT - 1.5 2.0 2.0 2.0
- 3G3M1-A2015-ECT 2.2 2.0 2.0 2.0
3G3M1-A2022-ECT - 2.0 2.0 2.0
- 3G3M1-A2022-ECT 3 2.0 2.0 2.0
3G3M1-A2037-ECT - 3.7 2.0 2.0 2.0
- 3G3M1-A2037-ECT 5.5 3.5 3.5 3.5
3G3M1-A2055-ECT - 3.5 3.5 3.5
3G3M1-A2075-ECT 3G3M1-A2055-ECT 7.5 5.5 5.5 5.5
3G3M1-A2110-ECT 3G3M1-A2075-ECT 11 5.5 5.5 5.5
3G3M1-A2150-ECT 3G3M1-A2110-ECT 15 5.5 5.5 5.5
3G3M1-A2220-ECT 3G3M1-A2150-ECT 18.5 8.0 8.0 8.0
- 3G3M1-A2185-ECT 22 8.0 8.0 8.0
2 Design
2-36
M1 Series EtherCAT Type User’s Manual (I670)
