Bit Symbol Description
15 -
Not used14 -
13 -
12 EN2
1 by input
11 EN1
10 -
Not used
9 -
8 -
7 -
6 DI5
1 by input
5 DI4
4 DI3
3 DI2
2 DI1
1 DI7
0 DI6
Output Signal Monitor [3010Hex-2AHex]
Bit Symbol Description
15 -
Not used
14 -
13 -
12 -
11 -
10 -
9 ROA, ROB 1 by output
8 -
Not used
7 -
6 -
5 -
4 -
3 -
2 -
1 -
0 DO1 1 by output
Communications Control Signal (Input/Output) Monitor
[3010Hex-2BHex, 3010Hex-2CHex]
The status of I/O by communication allocated to each bit for the communications control signal (input/
output) monitor is indicated by a four-digit hexadecimal.
The allocation for 0 to 15 bits of the terminal I/O status is described in the table below.
Communications Input Signal Monitor [3010Hex-2BHex]
8 Other Functions
8-10
M1 Series EtherCAT Type User’s Manual (I670)
