Index
(hex)
Sub-
index
(hex)
Pa-
rame-
ter No.
Function name Monitor or data range
Default
data
Set-
ting
dur-
ing
RUN
Unit
PDO
map
35 F52 Braking Resistor
Resistance
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.01 to 999
0.01
√
Ω Possible
51 F80 Load Mode Se-
lection
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0: HHD
1: HND
3: HD (only for 400 V)
4: ND (only for 400 V)
0 --- --- Possible
A-4-6
E Group Parameter List (Terminal Functions)
Index
(hex)
Sub-
index
(hex)
Pa-
rame-
ter No.
Function name Monitor or data range
Default
data
Set-
ting
dur-
ing
RUN
Unit
PDO
map
3005 02 E01 Input Terminal
[DI1] Function
Selection
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0 to 188 (normally-open input)
1,000 to 1,188 (normally-close input)
Refer to 8-2-1 Multifunction Input Se-
lection on page
8-23.
0 --- --- Possible
03 E02 Input Terminal
[DI2] Function
Selection
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0 to 188 (normally-open input)
1,000 to 1,188 (normally-close input)
Refer to 8-2-1 Multifunction Input Se-
lection on page
8-23.
1 --- --- Possible
04 E03 Input Terminal
[DI3] Function
Selection
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0 to 188 (normally-open input)
1,000 to 1,188 (normally-close input)
Refer to 8-2-1 Multifunction Input Se-
lection on page 8-23.
2 --- --- Possible
05 E04 Input Terminal
[DI4] Function
Selection
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0 to 188 (normally-open input)
1,000 to 1,188 (normally-close input)
Refer to 8-2-1 Multifunction Input Se-
lection on page
8-23.
7 --- --- Possible
Appendices
A-114
M1 Series EtherCAT Type User’s Manual (I670)
