Index
(hex)
Sub-
index
(hex)
Pa-
rame-
ter No.
Function name Monitor or data range
Default
data
Set-
ting
dur-
ing
RUN
Unit
PDO
map
28 F39 1st Stop Fre-
quency Holding
Time
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0.00 to 10.00
0.00
√
s Possible
29 F40 Torque Limit 1
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0 to 300
300
√
% Possible
2A F41 Torque Limit 2
2B F42 1st Drive Control
Selection
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0: IM V/f control
1: IM Dynamic torque vector control
without speed sensor
3: IM V/f control with speed sensor
4: IM Dynamic torque vector control
with speed sensor
5: IM Vector control without speed
sensor
6: IM V
ector control with speed sen-
sor
15: PM Vector control without speed
and pole position sensor
16: PM Vector control with speed
and pole position sensor
0 --- --- Possible
2C F43 1st Overload
Protect Function
Selection
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0: Disable
1: Enable at constant speed
2: Enable during ACC/constant
speed operation (Disable during
DEC)
2
√
--- Possible
2D F44 1st Overload
Protect Level
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
20 to 200
180
√
% Possible
33 F50 Electronic Ther-
mal for Braking
Resistor Dis-
charging Capaci-
ty
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
1 to 9,000
32,767: Disable
32,767
√
kWs Possible
34 F51 Electronic Ther-
mal for Braking
Resistor Allowa-
ble A
verage Loss
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0.001 to 99.99
0.001
√
kW Possible
Appendices
A-113
M1 Series EtherCAT Type User’s Manual (I670)
A-4 Lists of Manufacturer Specific Objects 2
(Inverter Parameters)
A
A-4-5 F Group Parameter List (Basic Functions)
To Next Page
