Index
(hex)
Sub-
index
(hex)
Pa-
rame-
ter No.
Function name Monitor or data range
Default
data
Set-
ting
dur-
ing
RUN
Unit
PDO
map
16 F21 1st DC Injection
Braking Level
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0 to 100 (HHD mode)
0 to 80 (HND/HD mode)
0 to 60 (ND mode)
Based on inverter rated current
0
√
% Possible
17 F22 1st DC Injection
Braking Time
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00: Disable
0.01 to 30.00
0.00
√
s Possible
18 F23 1st Starting Fre-
quency
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.0 to 60.0
0.5
√
Hz Possible
19 F24 1st Starting Fre-
quency 1 Holding
Time
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00 to 10.00
0.00
√
s Possible
1A F25 1st Stop Fre-
quency
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.0 to 60.0
0.2
√
Hz Possible
1B F26 Carrier Frequen-
cy
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0: 0.75
1 to 16
2
√
kHz Possible
1C F27 Motor Sound
Tone
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0: Level 0 (Disable)
1: Level 1
2: Level 2
3: Level 3
0
√
--- Possible
26 F37 1st V/f Charac-
teristics Selection
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0: Variable torque load
1: Constant torque load
1 --- --- Possible
27 F38 1st Stop Fre-
quency Detection
Method Selection
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0: Output frequency, Detected speed
1: Frequency reference
0 --- --- Possible
Appendices
A-112
M1 Series EtherCAT Type User’s Manual (I670)
