Parameters marked with * are for 1st control only. When using 2nd control, refer to 2nd Control Switch
Function (SET) on page 6-46 and replace these values.
9-1-3
Minor Fault Code List
Alarm
code
Alarm
subcode
Name Description 　 Check point and remedy reference
6D Hex
(CnT)
0000 Hex
Equipment
service life
(number of
startups)
(1) Equipment service
life (number of start-
ups)
-
Displayed when the motor number of
startups reaches the number set in 1st
Preset Startup Count for Motor Mainte-
nance (3008Hex-50Hex).
Additionally, the current number of start-
ups can be confirmed in 1st Startup
Count for Motor (3008Hex-2DHex),
therefore before reset, set
3008Hex-2DHex data to 0000.
67 Hex
(LiF)
0000 Hex
Life prediction (1) Life prediction -
Any one of the main circuit capacitor
used in the inverter, the electrolytic ca-
pacitor inside the inverter
, and the cool-
ing fan has reached the end of its life.
Referring to 8-8-10 Capacitor Life Warn-
ing Signal (WAC) on page 8-85,
8-8-13 Cooling Fan Life Warning Signal
(WAF) on page 8-88 and 8-8-14 Life
Alarm (LIFE) on page 8-88, check the
status of consumable parts.
66 Hex
(0H)
0000 Hex
Cooling fin
overheat pre-
diction
(1) Cooling fin over-
heat prediction
-
Displayed as a prediction before the
cooling fine overheat (alarm code: 11) oc-
curs. For measures, refer to cooling fine
overheat (alarm code: 1
1) ( page 9-17).
65 Hex
(0L)
0000 Hex
Motor over-
load prediction
(1) Motor overload
prediction
-
Displayed as a prediction prior to a motor
overload alarm (alarm code: 17, 18) oc-
curring, and sets the current value at
which the Overload early warning 2 Level
(OL2) (3005Hex-23Hex) operates.
Check that the actual current flowing in
the motor is not higher than the value set
in 3005Hex-23Hex.
69 Hex
(Pid)
0000 Hex
PID warning
output
(1) PID warning out-
put
-
Displayed when a warning (warning from
absolute value, warning from PID error)
is output during PID operation. For de-
tails, refer to Excessive PID deviation
(OD) on page 8-1
18.
68 Hex
(rEF)
0000 Hex
Command
loss
(1) Command loss -
When the analog frequency settings (ter-
minal AI1) command suddenly decreases
to 10% or less, it is judged to be a wire
break and a reference loss alarm (alarm
code: 68) is displayed. Check the wiring.
9 Troubleshooting
9-25
M1 Series EtherCAT Type User’s Manual (I670)
9-1 Alarm Display and Remedies
9
9-1-3 Minor Fault Code List
