Omron 3G3M1-A4110-ECT - Power on Time Over;Run Time (ONT;RNT)

Name Output signal
3005Hex-15Hex,
3005Hex-1CHex
allocated data
Operation level Hysteresis width
Range: 0.0 to
500.0Hz
Range: 0.0 to
500.0Hz
Set-frequency-only ar-
rival signal
FDT3 2 3005Hex-20Hex 3005Hex-1FHex
Set-frequency-only ar-
rival signal 2
FDT4 31 3005Hex-25Hex 3005Hex-1FHex
3005Hex-20Hex/3005Hex-25Hex
Output frequency
3005Hex-1FHex
3005Hex-1FHex
3005Hex-20Hex/3005Hex-25Hex
3005Hex-1FHex
3005Hex-1FHex
Set-frequency-only arrival signal “FDT3”
Set-frequency-only arrival signal 2 “FDT4”
ON ON
Frequency Match Detection (3005Hex-15Hex, 3005Hex-1CHex = 87:
FAR1FDT1)
This is an AND composite signal of FAR1 and FDT1, which turns ON when both the conditions are
established.
ONO
N
ON
ON
0
Over set frequency arrival
signal 1 “FDT1”
Frequency arrival signal 1
(constant speed) “FAR1”
Frequency match detection
“FAR1FDT1”
Output frequency
ON
ON
t
t
t
t
ON
3005Hex-21Hex
3005Hex-20Hex
3005Hex-1FHex
8-8-7
Power ON Time Over/RUN Time (ONT/RNT)
• If the total RUN time and power ON time of the inverter main circuit exceeds the time set at RUN
Time Over (RNT)/Power ON T
ime Over (ONT) Detection Level (301FHex-37Hex), the inverter will
output the RUN time over/Power ON time over (RNT/ONT) signal.
Parameter No. Function name Data
Default da-
ta
Unit
301FHex-37Hex
RUN time over (RNT)/Power
ON time over (ONT) Detection
Level
0 to 9999 0 10h
3005Hex-15Hex/
3005Hex-1CHex
Output Terminal [DO1] Func-
tion Selection/
Output T
erminal [ROA, ROB]
Function Selection
237: RNT (RUN time over)
236: ONT (Power ON time over)
- -
Related function
Cumulative Operation T
ime (3003Hex-15Hex)
Total RUN T
ime Monitor (3017Hex-50Hex)
8 Other Functions
8-81
M1 Series EtherCAT Type User’s Manual (I670)
8-8 Functions Related to Protection, Warning and Various Output Signals
8
8-8-7 Power ON Time Over/RUN Time (ONT/RNT)
