Parameter No. Item Range Display item
3017Hex-50Hex Total RUN Time Monitor 0 to 655350 hours
The cumulative time of the inverter
RUN state is displayed.
Measurement range: 0 to 655350 hours
If 655350 hours is exceeded, the accu-
mulation operation stops.
8-1-4
Alarm information
Parameter No. Item Range Display item
1 Latest alarm
3011Hex-15Hex
Latest Alarm Info. Output
Frequency
0.00 to 99.99,
100.0 to 590.0
[Hz]
The output frequency before slip com-
pensation is displayed in increments of
0.01 Hz. A value of 100.0 Hz or higher
is displayed in increments of 0.1 Hz.
3011Hex-16Hex
Latest Alarm Info. Output
Current
0.00 to 99.99,
100.0 to 655.3 [A]
The output current is displayed. A cur-
rent value of 100.0A or higher is dis-
played in increments of 0.1 A.
Display unit: A (Ampere)
3011Hex-17Hex
Latest Alarm Info. Output
Voltage
0 to 999 [V]
The output voltage is displayed.
Display unit: V (Volt)
301
1Hex-18Hex
Latest Alarm Info. Torque
Monitor
-400 to 400 [%]
The torque calculated value is dis-
played.
3011Hex-19Hex
Latest Alarm Info. Fre-
quency Command
0.00 to 99.99,
100.0 to 590.0
[Hz]
The set frequency is displayed.
3011Hex-1AHex
Latest Alarm Info. Running
Status 1
0000Hex to
FFFFHex
The operation status is displayed by a
four-digit hexadecimal.
0000 to FFFF hex
Bit 15: BUSY (During function code da-
ta writing)
Bit14: -
Bit13: -
Bit12: RL (Communications ef
fective)
Bit1
1: ALM (Alarm relay)
Bit10: DEC (During deceleration)
Bit9: ACC (During acceleration)
Bit8: IL (During current limiting)
Bit7: VL (During voltage limiting)
Bit6: TL (Torque limiting)
bit5: NUV (Main circuit DC voltage es-
tablished)
Bit4: BRK (During braking)
Bit3: INT (Inverter shut down)
Bit2: EXT; During DC braking or during
pre-exciting
Bit1: REV (During reverse operation)
Bit0: FWD (During forward operation)
3011Hex-1BHex
Latest Alarm Info. Cumula-
tive Ope. time
0 to 655,350 hours
The cumulative inverter run time (the
time when the main power supply is
ON) when an error occurs is displayed.
