Parameter No. Item Range Display item
3003Hex-57Hex Latest Light Alarm Factor
00 hex to FF hex
The contents of the minor alarm that oc-
curred recently, the last to third last time
are displayed by a code.
0 to 254 (00 hex to FE hex)
0(0x00): No alarm
17(0x1
1): OH1; Heat sink overheat
18(0x12): OH2; External alarm input
19(0x13): OH3; Inverter internal over-
heat
22(0x16): dbH; Braking resistor over-
heat
23(0x17): OL1; Motor 1 overload (elec-
tronic thermal overload relay)
24(0x18): OL2; Motor 2 overload (elec-
tronic thermal overload relay)
34(0x22): Er4; Option card communica-
tions error
35(0x23): Er5; Option card error
47(0x2F): ErE; Following error (exces-
sive speed deviation)
53(0x35): ErP; RS-485 communications
error (Option card)
56(0x38): Ero; Position control error
58(0x3A): CoF PID feedback discon-
nection detected
100(0x64): FAL; Detect DC fan lock
101(0x65): OL; Motor overload early
warning
102(0x66): OH; Heat sink overheat ear-
ly warning
103(0x67): LiF; Lifetime alarm
104(0x68): rEF; Reference loss
105(0x69): Pid; PID alarm
106(0x6A): UTL; Low output torque de-
tection
107(0x6B): PTC PTC thermistor activat-
ed
108(0x6C): rTE; Inverter life (Cumula-
tive run time)
109(0x6D): CnT; Inverter life (Number
of startups)
3003Hex-58Hex Light Alarm Factor Last
3003Hex-59Hex
Light Alarm Factor 2nd
Last
3003Hex-5AHex Light Alarm Factor 3rd Last
3017Hex-3EHex
Braking Resistor Thermal
Monitor
0.0 to 100.0%
The percentage of the electronic ther-
mal calculated value for motor protec-
tion at the current moment is displayed.
If the percentage reaches 100.0%, the
dBH alarm occurs.
3003Hex-3CHex
Motor Electronic Thermal
Monitor
0.0 to 100.0%
The percentage of the electronic ther-
mal calculated value for motor protec-
tion at the current moment is displayed.
If the percentage reaches 100.0%, the
OL1 (1st motor overload) or OL2 (2nd
motor overload) (depending on whether
the 1st control or 2nd control is select-
ed) occurs.
8 Other Functions
8-15
M1 Series EtherCAT Type User’s Manual (I670)
8-1 Status Monitors
8
8-1-3 Maintenance Information
