Index
(hex)
Sub-
index
(hex)
Pa-
rame-
ter No.
Function name Monitor or data range
Default
data
Set-
ting
dur-
ing
RUN
Unit
PDO
map
0B F10 1st Motor Elec-
tronic Thermal
Characteristic
Selection
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
1: For a general-purpose motor with
shaft-driven cooling fan
2: For an inverter-driven motor non-
ventilated motor or motor with sepa-
rately powered cooling fan
1
√
--- Possible
0C F11 1st Motor Elec-
tronic Thermal
Level
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00: Disable
0.01 to 118.8
Setting range from 1% (HHD) to
135% (ND) of the rated inverter cur-
rent
21
√
A
Possible
0D F12 1st Motor Elec-
tronic Thermal
Time Constant
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.5 to 75.0
5
√
min Possible
0F F14 Power Interrup-
tion Restart
Mode Selection
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0: Immediately trip (Free run stop)
1: Trip after a recovery from power
failure (Free run stop)
2: T
rip after decelerate-to-stop
3: Continue to run
4: Restart at the frequency selected
by E152
6: Decelerate-to-stop (w/o trip)
1
√
--- Possible
10 F15 1st Frequency
Upper Limit
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00 to 590.00
70.00
√
Hz Possible
11 F16 1st Frequency
Lower Limit
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00 to 590.00
0.00
√
Hz Possible
13 F18 Input Terminal
[AI1, AI2] Bias for
1st Frequency
Command
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
-100.00 to 100.00
0.00
√
% Possible
15 F20 1st DC Injection
Braking Start
Frequency
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.0 to 60.0
0.0
√
Hz Possible
Appendices
A-111
M1 Series EtherCAT Type User’s Manual (I670)
A-4 Lists of Manufacturer Specific Objects 2
(Inverter Parameters)
A
A-4-5 F Group Parameter List (Basic Functions)
