The figures below show the components of each Inverter model.
Single-phase 200 V, 0.1/0.2/0.4/0.75 kW
Three-phase 200 V
, 0.1/0.2/0.4/0.75 kW
Single-phase 200 V, 1.5 kW
Three-phase 200 V, 1.5/2.2 kW
Three-phase 400V
, 0.4/0.75/1.5/2.2kW
(1) Cooling Fan Cover (4) Inverter Case
(2) Cooling Fan (5) Surface cover (Terminal block cover)
(3) Cooling Fin (6) Surface cover (Backing plate)
Note
The single-phase 200-V, 1.5-kW and three-phase 200-V, 1.5-kW models have a cooling fan.
The three-phase 400-V, 0.4/0.75/1.5 kW model, however, has no cooling fan.
1 Overview
1-7
M1 Series EtherCAT Type User’s Manual (I670)
1-2 Appearance and Part Names
1
