Index
(hex)
Sub-
index
(hex)
Pa-
rame-
ter No.
Function name Monitor or data range
Default
data
Set-
ting
dur-
ing
RUN
Unit
PDO
map
08 W07 Output Torque
Monitor
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
-999 to 999
0 --- % Possible
(TxPDO)
09 W08 Rotate Speed
Monitor
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00 to 99,990
0 --- r/min Possible
(TxPDO)
0A W09 Load Shaft
Speed
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00 to 99,990
0 --- r/min Possible
(TxPDO)
0B W10 Feed Speed
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00 to 99,990
0 --- m/min Possible
(TxPDO)
0C W11 PID Process
Command
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
-999.00 to 9,990.00
0 --- --- Possible
(TxPDO)
0D W12 PID Feedback
Value Monitor
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
-999.00 to 9,990.00
0 --- --- Possible
(TxPDO)
0E W13 Analog Torque
Limit Value Moni-
tor
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
-300 to 300
300 --- % Possible
(TxPDO)
0F W14 Reserved Do not use. --- --- --- ---
10 W15 Ratio value Moni-
tor
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00 to 200.00
0 --- % Possible
(TxPDO)
11 W16 Motor Speed Set
Value
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00 to 99,990
0 --- r/min Possible
(TxPDO)
12 W17 Load Shaft Set
Value
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00 to 99,990
0 --- r/min Possible
(TxPDO)
13 W18 Feed Speed Set
Value
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00 to 99,990
0 --- m/min Possible
(TxPDO)
14 W19 Transport Time
Set Value for
Specified Length
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00 to 99,990
999.9 --- min Possible
(TxPDO)
Appendices
A-65
M1 Series EtherCAT Type User’s Manual (I670)
A-4 Lists of Manufacturer Specific Objects 2
(Inverter Parameters)
A
A-4-2 W Group Parameter List (Monitor 2)
