Sub-
index
(hex)
Pa-
rame-
ter No.
Function name Monitor or data range
Default
data
Set-
ting
dur-
ing
RUN
Unit
PDO
map
4A X73 Last Alarm Info.
Input Terminal
via Communica-
tion
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0000 to FFFF hex
Bit 15: RST
Bit 14: DI7
Bit 13: DI6
Bit 12: ---
Bit 11: ---
Bit 10: ---
Bit 9: ---
Bit 8: ---
Bit 7: ---
Bit 6: DI5
Bit 5: DI4
Bit 4: DI3
Bit 3: DI2
Bit 2: DI1
Bit 1: REV
Bit 0: FWD
0 --- --- Possible
(TxPDO)
4B X74 Last Alarm Info.
Output Terminal
via Communica-
tion
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0000 to FFFF hex
Bit 15: ---
Bit 14: ---
Bit 13: ---
Bit 12: ---
Bit 11: ---
Bit 10: ---
Bit 9: ---
Bit 8: RO
Bit 7: ---
Bit 6: ---
Bit 5: ---
Bit 4: ---
Bit 3: ---
Bit 2: ---
Bit 1: DO2
Bit 0: DO1
0
--- --- Possible
(TxPDO)
