(6) The value of 1st Manual
Torque Boost V
oltage (3004-0A
hex) is too high.
Check and readjust the value of
1st Manual Torque Boost
Voltage (3004-0A hex) so that
lowering the value does not
cause a stall.
→ Adjust the value of 1st
Manual Torque Boost Voltage
(3004-0A hex).
Set the value of 1st Manual
Torque Boost Voltage (3004-0A
hex) appropriately.
(7) The V/f settings are incorrect. Check that the 1st Base
Frequency (3004-05 hex) and
1st Rated Voltage at Base
Frequency
(3004-06 hex) match
the values on the motor rating
nameplate.
→ Match the data to the value on
the motor rating nameplate.
Configure the V/f settings appro-
priately.
(8) There is an incorrect parame-
ter setting.
The function of Thermistor
Function Selection (MOH)
(3008-1B hex) is enabled even
though the PTC thermistor is not
used.
→ Change the setting of
Thermistor Function Selection
(MOH) (3008-1B hex) to 0 (Disa-
ble).
Set the value of
Thermistor
Function Selection (MOH)
(3008-1B hex) appropriately.
Attached in-
formation
None
Precautions/
Remarks
None
Event name Communication Timeout with Sysmac Studio Event code 96530000 hex
Meaning A communication timeout occurred in the connection between Sysmac Studio and the Safety CPU Unit.
Source EtherCAT Master Function Mod-
ule
Source details Slave Detection tim-
ing
Continuously
Error attrib-
utes
Level Information Recovery --- Log category System log
Effects User program Continues. Operation Not affected.
Indicators EtherCAT NET RUN EtherCAT NET ERR EtherCAT LINK/ACT
--- --- ---
System-de-
fined varia-
bles
Variable Data type Name
None None None
Cause and
correction
Assumed cause Correction Prevention
(1) A communications cable is
broken.
Do not interrupt the communica-
tions with Sysmac Studio while
the Safety CPU Unit is operating
in DEBUG mode.
Perform debugging according to
the corrections that are given on
the left.
Attached in-
formation
None
Precautions/
Remarks
None
Appendices
A-285
M1 Series EtherCAT Type User’s Manual (I670)
A-5 Sysmac Error Status Codes
A
A-5-2 Error Descriptions
