Model
Maxi-
mum
appli-
cable
motor
ca-
paci-
ty
[kW]
Recommended wire size [mm
2
] Maximum applicable motor
capacity [kW]
Main power supply input (L1/R, L2/S, L3/T)
When DC reactor (DCR) is
used
Without DC reactor (DCR)
HD mode ND mode
Allowable tempera-
ture (Note 1)
Cur-
rent
value
[A]
Allowable tempera-
ture (Note 1)
Cur-
rent
value
[A]
60°C 75°C 90°C 60°C 75°C 90°C
3G3M1-
A4004-ECT
3G3M1-
A4004-ECT
0.75 2.0 2.0 2.0 1.5 2.0 2.0 2.0 2.7
3G3M1-
A4007-ECT
- 1.1 2.0 2.0 2.0 2.1 2.0 2.0 2.0 3.9
- 3G3M1-
A4007-ECT
1.5 2.0 2.0 2.0 2.9 2.0 2.0 2.0 4.8
3G3M1-
A4015-ECT
3G3M1-
A4015-ECT
2.2 2.0 2.0 2.0 4.2 2.0 2.0 2.0 7.3
3G3M1-
A4022-ECT
3G3M1-
A4022-ECT
3 2.0 2.0 2.0 5.8 2.0 2.0 2.0 11.3
3G3M1-
A4030-ECT
3G3M1-
A4030-ECT
5.5 2.0 2.0 2.0 10.1 2.0 2.0 2.0 16.8
3G3M1-
A4040-ECT
3G3M1-
A4040-ECT
3G3M1-
A4055-ECT
- 7.5 2.0 2.0 2.0 14.4 3.5 2.0 2.0 23.2
3G3M1-
A4075-ECT
3G3M1-
A4055-ECT
11 2.0 2.0 2.0 21.1 5.5 3.5 2.0 33.0
3G3M1-
A41
10-ECT
3G3M1-
A4075-ECT
15
3.5 2.0 2.0 28.8 8.0 5.5 3.5 43.8
3G3M1-
A4150-ECT
3G3M1-
A4110-ECT
18.5
5.5 3.5 3.5 35.5 14.0 8.0 5.5 52.3
3G3M1-
A4185-ECT
3G3M1-
A4150-ECT
22 8.0 5.5 3.5 42.2 14.0 8.0 5.5 60.6
3G3M1-
A4220-ECT
3G3M1-
A4185-ECT
30 14.0 8.0 5.5 57.0 22.0 14.0 8.0 77.9
- 3G3M1-
A4220-ECT
37 14.0 14.0 8.0 68.5
38
*1
14.0 14.0 94.3
Model
Maxi-
mum
appli-
cable
motor
ca-
paci-
ty
[kW]
Recommended wire size [mm2]
Inverter output (U, V, W)
HD mode ND mode
HD mode ND mode
Allowable tempera-
ture (Note 1)
Cur-
rent
value
[A]
Allowable tempera-
ture (Note 1)
Cur-
rent
value
[A]
60°C 75°C 90°C 60°C 75°C 90°C
3G3M1-
A4004-ECT
3G3M1-
A4004-ECT
0.75 2.0 2.0 2.0 1.8 2.0 2.0 2.0 2.1
3G3M1-
A4007-ECT
- 1.1 2.0 2.0 2.0 3.4 - - - -
2 Design
2-39
M1 Series EtherCAT Type User’s Manual (I670)
2-3 Wiring
2
2-3-4 Wiring for Main Circuit Terminals
To Next Page
