A-4 CP1L Programming Examples
SYSMAC CP1L/CP1E Introduction Manual 127
4. On the IN0 (CP1E: IN4) drop-down list for Interrupt Input, select [Quick].
While the sensor input contact is 0.04, setup is performed for [IN0 (CP1E:
IN4)] since the interrupt input / quick-response input setting is set to
0(CP1E: 4).
5. Close the PLC Settings dialog box.
6. To apply changes made to the PLC settings, turn the PLC power ON.
■Programming Example
●Ladder Program
CNT
0000
#0100
100.00
Count complete
C0000
Sensor input
0.04
0.01
Counter reset input
BCD counter
To Next Page
