A
A-5 Comparison between CP1L and CP1E
172 SYSMAC CP1L/CP1E Introduction Manual
Appendix
A-5 Comparison between CP1L and CP1E
The following table shows the differences between the CP1L CPU Units and CP1E CPU Units
A-5-1 Differences between CP1L and CP1E
■Functional Specifications
Item CP1L CPU Units CP1E E-type CPU Units CP1E N-type CPU Units
Maximum number of I/O points 10 to 180 points 20 to 160 points
Maximum number of Expansion
Units and Expansion I/O Units
that can be connected
CP1L L-type CPU Unit: 1
CP1L M-type CPU Unit: 3
CPU Unit with 20 I/O Points: None
CPU Unit with 30 or 40 I/O Points: 3
Power supply AC or DC power supply Only AC power supply AC or DC power supply
Output types Relay or transistor outputs Only relay outputs Relay or transistor outputs
Terminal block Removable. Irremovable.
Power supply to external
devices (service power)
Only AC power supply
CPU Unit with 30, 40 or 60
I/O Points: 300mA
CPU Unit with 10, 14 or 20
I/O Points: 200mA
Only AC power supply
CPU Unit with 30 or 40 I/O Points: 300mA
CPU Unit with 20 I/O Points: None
Program capacity CP1L L-type CPU Unit:
5K steps
CP1L M-type CPU Unit:
10K steps
(Not including comments,
symbol tables, and program
indexes.)
2K steps
(Including comments,
symbol tables, and program
indexes.)
8K steps
(Including comments,
symbol tables, and program
indexes.)
DM Area capacity CP1L L-type CPU Unit:
10K words
CP1L M-type CPU Unit:
32K words
2K words
D0 to D1499 can be backed
up to EEPROM.
8K words
D0 to D6999 can be backed
up to EEPROM.
Program language Ladder
ST (Only in the function
block definition)
Only ladder
Function block Provided. Not provided.
SFC Not provided. Not provided.
Instruction set Approx. 500 instructions Approx. 200 instructions
Instruction execution time LD: 0.55µs
MOV: 4.1µs
LD: 1.19µs
MOV: 7.9µs
