Transferring and Debugging Programs
5
84 SYSMAC CP1L/CP1E Introduction Manual
5
Transferring and Debugging Programs
5-1 Going Online
To configure CP1L settings, transfer programs, or execute programs, the computer and CP1L must first
be online.
1. In CX-Programmer, open the program to be transferred.
2. Select [PLC] - [Work Online] from the main menu.
A dialog box will be displayed to confirm going online.
3. Click [Yes].
The dialog box will be closed.
When the system goes online, the ladder section window will turn light grey.
Online status is one in which the computer and CP1L are connected. To
execute a program created with CX-Programmer on CP1L, the program will
need to be transferred. For details on transferring programs, refer to 5-1-3
Transferring Programs.
To Next Page
