Sheet 1
Sheet 1
A sheet is a screen that contains objects commonly used on several screens.
In this manual, you will create a sheet with a “Switch Label” function to switch
labels between English and Dutch, a function to display a screen (to be
described later) for generating a virtual alarm, and a function to switch screens.
Virtual Alarm
Display Button
Screen Switch Buttons
1. Switch Label Button
Press this button to show a pop-up menu from which you can switch a label in
English and Dutch.
2. Virtual Alarm Display Button
Press this button to display the pop-up screen (to be described later) with a
Virtual Alarm Display button.
3. Screen Switch Button
Press a button to display the screen number (1 to 3) shown on the button .
Switch Label Button
Start up
CX-D
Creating a
new project
Project
property
System
setting
Creating
a screen
Validation
Transferring
a project
To Next Page
