Create a label as shown
on the right by referring
to “9 Display a Text.
[Label]
! “Frame”
Right-click the object
and select [Property] from
the pull-down menu.
14. Frame
14. Frame
Frame is an object that changes a displayed text on objects that have a page
switch function. In this manual, a frame is used to switch a low alarm and a high
alarm display.
Select the icon
and drag it until you get
the size you want.
Start up
CX-D
Creating a
new project
Project
property
System
setting
Creating
a screen
Validation
Transferring
a project
