Creating Third Screen
Click
A new screen is created.
17. Alarm/Event Display
17. Alarm/Event Display
Alarm/Event Summary is a functional object that displays a current recorded
alarm/event in one line. Normally, the highest priority alarm/event is displayed, buy it
is also possible to display more than one alarm/event occurring at the same time
according to the priority by specifying flowing string. In this manual,
It is used to display low alarm, high alarm, and running status (event).
[Label]
! “Alarm/Event Display”
Create three labels by
referring to “13. Add a
Screen”.
Create a label as shown
on the right by referring
to “9. Displaying a Text”.
Start up
CX-D
Creating a
new project
Project
property
System
setting
Creating
a screen
Validation
Transferring
a project
To Next Page
