Omron CX-DESIGNER - INTRODUCTION GUIDE - Test Function

24. Test function
24. Test function
Click the [Test]
button.
Before transferring the data, you can check it on the CX-Designer.
Click the [Start]
button.
The first screen “0000:
Screen Page 1” and the
Test Tool dialog appear.
It is possible to confirm
actual movement on NS 8
by clicking a functional
object (a button, etc…).
It is possible to confirm
actual movement on NS 8
by clicking a functional
object (a button, etc…).
You can directly change
values on the Test Tool
dialog.
You can directly change
values on the Test Tool
dialog.
Start up
CX-D
Creating a
new project
Project
property
System
setting
Creating
a screen
Validation
Transferring
a project
