[Confirming a movement of ON/OFF buttons and bit lamps of “Power Supply 1 to 5”.]
The Power Supply (1
to 3) bit lamps will lit
by turning ON the
ON/OFF buttons.
You can check that
the addresses of the
Power Supply (1 to 3)
is turned ON on the
Test Tool dialog.
Click the Screen 2.
[Check the ON/OFF buttons and bit lamps of Alarms.]
Click the Virtual Alarm
Display.
Start up
CX-D
Creating a
new project
Project
property
System
setting
Creating
a screen
Validation
Transferring
a project
