Select as follow:
[No. of Frames]
! “2”
Select a color
Check the [Frame with a
tab] box.
[Height] ! “2”
Set as follow from the
address setting menu.
Host Name
! [PT memory]
Area Name
! [Internal memory
($W)]
Word
! [1]
Click
Start up
CX-D
Creating a
new project
Project
property
System
setting
Creating
a screen
Validation
Transferring
a project
