Omron CX-DESIGNER - INTRODUCTION GUIDE - Page 25

Text tab
[Label]
! “Screen 1”
[Horizontal Position]
! “Center”
Select the [Layout/Frame]
tab.
Check “Three-dimensional
Frame” check box.
Set “2” to [Size].
Click
Click the [General] tab on
the property list.
Click the [Background
Color] and select a color.
to switch to the [Dutch]
label.
Set the following items on
the property list.
Click
to switch back to the
[English] label.
Completed image
Start up
CX-D
Creating a
new project
Project
property
System
setting
Creating
a screen
Validation
Transferring
a project
