Right-click [0003:
Pop-up Screen 1] in the
Project Workspace to
display the menu.
Click “Screen Property”
from the menu.
Click the [Size/Pop-up] tab.
The Screen Property
Dialog appears.
Set screen size as follow:
[Width]
! “320”
[Height]
! “240”
Check “Use as Pop-up
Screen”.
[Pop-up Screen Display
Position]
! “Center of Screen”
[Pop-up Screen Setting]
! Check “Enable input on
Other screens”.
Start up
CX-D
Creating a
new project
Project
property
System
setting
Creating
a screen
Validation
Transferring
a project
